What was the purpose of the Kenwood kr-9400?

The KR-9400 is the culmination of years of research and development on the part of Kenwood’s engineering team, who have designed this very special unit with but one purpose in mind; to achieve the highest possible performance, regardless of cost.

What kind of filter does Kenwood kr-7050 have?

Some of its quoted specs, particularly for sensitivity, surpass Kenwood’s specs for stand-alone tuners like the KT-7500. All of these models have wide/narrow IF selection. The KR-7050 has 5 ceramic filters, two of which have a 180 kHz bandwidth and are used in Narrow mode.

Where does the detector go on a Kenwood tuner?

The detector output goes directly to the LA3350 MPX IC input. The MPX output then passes through a pilot filter then buffered by a discrete 2SA733 common emitter buffer before the muting IC AN6135. [This piece] had an issue on both ends of the audio band.

What kind of separation does a kr-9400 have?

The kR-9400 provides extremely high FM-stereo separation throughtout the audio spectrum, thanks to the newly developed phase-lock-loop IC circuit incorporated in the stereo FM decoder section, achieving more than 45 dB separation at 1 kHz; better than 35 dB at all frequencies from 30 Hz to 10 kHz.

What kind of lamp is a Kenwood kr-4010?

Kenwood KR-4010/5010/5510/6050/6650/5510 Receiver-front-dial-LED lamps FREE SHIPPING. 3 pcs.+ 6 wire crimpers. Dial lamps LED with wires.. ORIGINAL WARM WHITE color , AC voltage. Handmade. You will cut your bad lamp, removed it from rubber bushing and install new one using existing rubber bushings and isolate by wire crimpers.

What do you need to replace a Kenwood kr-8050?

Vintage Kenwood KR-9050 / KR-8050 / KR-11000 AC power cord replacement. New. Power cord replacement. Power cord with wire protector and 2 wire crimps. Old power cord you have to remove by squeezing Nylon Strain Relief Bushing from inside receiver ,not from outside.

How to fix Kenwood kr-6340 dial light panel?

Specifically design for Kenwood KR-5340 / KR-6340 / L-07T dial panel . You will remove bad lamp from rubber boot , insert new ones in existing rubber boot , fix wires like on pictures and install back on dial light panel. Free shipping in USA.

The KR-9400 is the culmination of years of research and development on the part of Kenwood’s engineering team, who have designed this very special unit with but one purpose in mind; to achieve the highest possible performance, regardless of cost.
